The antique Glazed roll forming machine formed by roll punching with 800 imitation resin Glazed roll forming machine have the characteristics of beautiful appearance, simple and ele
The antique Glazed roll forming machine formed by roll punching with 800 imitation resin Glazed roll forming machine have the characteristics of beautiful appearance, simple and elegant, elegant and unique shape, etc.,and can be widely used in garden-style factories, tourist attractions, pavilions, guest villas, exhibition halls, and resorts. , homes and other buildings and outdoor decoration. The 800 imitation resin Glazed roll forming machine is mainly composed of a feed introduction platform, a steel plate forming automatic shearing device, a hydraulic system, a computer control system for the incoming movement, a glazed ladder press, and an automatic measuring length system with suitable accuracy.

| Name (Имя) | 800 imitation resin Glazed roll forming machine (800 имитация смолы глазурованная роликовая формовочная машина) |
| Overall dimensions (Габаритные размеры) | 5800mm*1300mm81200mm (5800мм*1300мм81200мм) |
| Large frame material (Материал большой рамы) | 250 channel steel (250 швеллерная сталь) |
| Forming shaft (Формовочный вал) | Diameter 68mm 45# tempered (Диаметр 68мм 45# закаленная) |
| Transmission mode (Режим передачи) | sprocket, chain (звездочка, цепь) |
| Machine motor (Двигатель машины) | 3KW (3КВт) |
| Row number (Номер ряда) | 11 rows (11 рядов) |
| Shearing mold (Форма-нож) | Gr12 (Gr12) |
| Molding speed (Скорость формования) | 1-2.5m/min (1-2,5м/мин) |
| Pressing thickness (Толщина прессования) | 0.2-0.7mm (0,2-0,7мм) |
| Pressing width (Ширина прессования) | 1000m (1000м) |
